Softail XC Mountain Bike (Disc Brakes, 29er)

Race-Ready Full Suspension: Built for cross-country racing and trail riding, this full suspension mountain bike delivers the speed, efficiency, and control needed to excel on both race courses and your favorite technical trails.
Increased Front Suspension Travel: Enhanced front travel absorbs the impact of rough terrain, providing better control and stability, allowing you to ride the optimal line with confidence on challenging sections.
Perfect Balance of Speed & Control: The upper shock with short travel is the ideal combination of fast and responsive handling while keeping the rear wheel glued to the trail, offering superior traction and control over rough terrain.
Smooth & Efficient Power Transfer: Designed to keep you moving quickly without compromising comfort, this bike offers efficient pedaling and a stiff frame for maximum power transfer on climbs and sprints.
Precision Handling on Technical Terrain: The full-suspension system ensures excellent traction and responsiveness, helping you stay in control through roots, rocks, and loose trails, especially when navigating technical descents.
Lightweight & Agile: A lightweight frame and optimized suspension allow for quick acceleration and agile handling, making this bike perfect for both fast races and technical trail adventures.
Stable & Confident Descents: With added suspension travel and a well-tuned rear shock, this bike remains stable during fast descents, allowing you to maintain control and ride with confidence on technical downhill sections.
Built for XC Races & Trail Adventures: Whether you're gearing up for an intense cross-country race or exploring rugged trails, this bike provides the perfect balance of performance, comfort, and durability for all types of off-road cycling.
Durability Meets Efficiency: Designed to handle the rigorous demands of cross-country racing while maintaining efficiency and durability on rough terrain, this bike is built to last.
Smooth Ride, Maximum Performance: The combination of long front suspension travel and a short travel rear shock provides the best of both worlds: comfort over rough terrain and the speed needed to stay ahead of the competition.

Quercus Specifications
Frame
29er Cross Country Mountain Bike
Sizes
Small (15.5”), Medium (17.5”), Large (19”)
Front Travel
120mm
Headset
Tapered 1-⅛” - 1-½”  Standard Headset
Bottom Bracket
Threaded BSA73
Brakes
Post mount disc brakes - 160mm Ø Discs, 180mm Ø with adapter
Seatpost
31.6mm Ø
Dropper Lengths
Max Length Dropper -  190mm (Small) / 200mm (Med) / 220mm (Lrg)
Tire Clearance
29er - 2.35”
Chainring
30T min, 36T max
Shock
190mm x 45mm Standard Mount only - 90mm Travel
Dropout
Thru Axle 12*148mm
Weight
2050g (Med), without Shock


Quercus Geometry

Size
Small
Medium
Large
Stack
587mm
597mm
606mm
Reach
410mm
435mm
460mm
Top Tube (Horiz)
570mm
598mm
625mm
Wheelbase
1131mm
1160mm
1189mm
Chainstay
440mm
440mm
440mm
BB  Drop
38mm
38mm
38mm
BB Height
335mm
335mm
335mm
Front Center
723mm
723mm
752mm
Seat Tube Angle
75°
75°
75°
Head Tube Angle
67.5°
67.5°
67.5°
Standover
745mm
745mm
747mm
Seat Tube Insert Length
190mm
200mm
220mm
Fork Rake / Offset
51mm
51mm
51mm
Trail
114mm
114mm
114mm

Quercus Build Options
Group
A
B
C
SRAM
GX Eagle
XO Eagle AXS
XX  Eagle AXS

SID Select
SID Ultimate
SID Ultimate FA





Named for a Trail in San Luis Obispo (Lat 35.32174, Long -120.63333)
